00:00:00

The original landing zones are delivered in a GitHub repository and Branch Based integration of config files

The collectors edition offers the original format - enhanced with extended input operations by accepting web-hook calls into the repository - passing the config via json

This boiler-plate enhancement allows for custom entry points - and we include a webform POST request

Using the Collectors Edition enhancements as working examples, power users can build integrations using their preferred platform (slack, teams) and interface in the same way

For true integration, setup your existing management tools to call using web-hooks!

00:01:00 - inputs

The basic execution of the Azure Subscriptions Landing Zone was just that - the user prompted for a few values and submitting the request

The collectors edition really interacts with the user to offer a diverse range of options to compliment their request- collating the users requirements to deliver features that are - in some cases required to et going - in others, trying to deliver as much as possible with minimal fuss

Delivering the code as small add=ons that contain all their own variables etc. we start to deliver real value for the user - and they should be able to see the patterns and customise themselves - or possible deliver to the practice for integration

00:69:00 - Delivery

vchfgh

04:20:00 - Outputs

By pulling possible dependent resources into the optional features, we can start to remove the human element and outputs form inputs for the process

Azure EA Subscription Creation

This module helps you to keep consistency on your resources names for Terraform The goal of this module it is that for each resource that requires a name in Terraform you would be easily able to compose this name using this module and this will keep the consistency in your repositories.

Usage

The module can either be called directly

module "azurerm_ea_subscription" {
    source="../"

    billing_account         = <value>
    enrollment_account      = <value>

    owner                   = <value>
    email                   = <value>
    purpose                 = <value>
    alias                   = <value>

    # optional parameters
    apply_budget            = <value>
    management_group        = <value>

    create_service_principal = <value>
    service_principal_display_name = <value>

    create_automation_repo  = <value>
    github_username         = <value>
    template_repo_org       = <value>
    template_repo           = <value>
}

or, in a preferred configuration, by identifying config files in the subscription_configurations folder - each file iterated over to deliver a new subscription with all of the options as set in the <any_filename>.json files

locals {
    json_files = fileset(path.module, "subscription_configurations/*json")
    json_data  = [ for f in local.json_files : jsondecode(file("${f}")) ]
}


module "azurerm_ea_subscription" {
    source="../"

    for_each = { for f in local.json_data : f.owner => f }

    all_variables_as_above  = each.value.variable_name_from_config_file

}

Operating Guidance

1. This terraform requires very high role assignments and should ony be operated by automation with all secret values from secret stores

2. For each user, assuming all optional extra's are set to true, will

• Identify the new subscription requestor in AD via their email address

• Create a subscription under the supplied Billing Account and Enrolment account details provided

• Add a subscription alias if provided

optionally

• Assign the included budget and budget notification scheme

• Assign the subscription into the supplied Management Group (if one is supplied)

• Create a GitHub repository to store automation code for this subscription

• Create a service principal to run automation from Github

• Create the repository from either a supplied template repository, or if not, a blank repo

• Pre-populate all the sensitive values for automation by storing the SP details in the Repository Secrets

• Assigning appropriate roles for teh requester for all resources

Trigger by Web-hook

This repository can be triggered remotely for further integration with other systems

curl  -H "Authorization: token <token>" \\
      -H 'Accept: application/vnd.github.everest-preview+json' \\
      "<https://api.github.com/repos/<owner>/<repository_name>/dispatches">
      -d '{"event_type": "subscription-request", "client_payload": {"billing_account" : "87561154", "enrollment_account" : "311200","owner" : "paul.kelleher","email" : "paul.kelleher@contino.io","purpose" : "subscription_purpose","alias" : "subscription_alias","apply_budget" : true,"management_group" : "UK","create_automation_repo" : true,"github_username": "pknw1","template_repo_org" : "pknw1","template_repo" : "terraform-boilerplate","create_service_principal" : true,"service_principal_display_name" : "subscription_name_subscription"}}'

In sending the request and triggering the workflow, the POST body is stored as a subscription_configurations/*json file and can be committed either directly to main
and processed - or if some approvals were required, into a new branch with a PR

name: example-client-payload-action
on:
  repository_dispatch:
    types: [subscription-request]
jobs:
  easub:
    name: EA Subscription
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v2
      - run: 'echo "field: ${{ github.event.client_payload.foo }}"'
      - run: 'echo "payload: ${{ toJson(github.event.client_payload) }}"'
      - run: echo baz
        if: github.event.action == 'baz'
      - run: 'echo "payload: ${{ toJson(github.event.client_payload) }}" > newfile.txt'
      - run: 'cat newfile.txt'

Terraform Init and Plan

• Terraform Init and Plan Recording

 Terraform Apply

* Terraform Apply Recording
